    Hot Sale Automobile Repair Car Painting Spray Booth

    Ask Lasest Price
    Brand Name : TARGET
    Model Number : TG-60C
    Certification : CE,ISO
    Price : $6000---8000
    Payment Terms : T/T, L/C
    Supply Ability : 1000set/month
    Delivery Time : 5--7 days
    • Product Details
    • Company Profile

    Hot Sale Automobile Repair Car Painting Spray Booth

    Hot Sale Automobile Repair Car Painting Spray Booth


    Spray Booth Diesel Burner TG-60C
    Inside dimension6900*4000*2800 (LxWxH)Front door(mm)3000*2700 mm(W×H)
    Outside dimension7050*5560*3500 (LxWxH)Total Power(Kw)18 Kw , Noise < 80db
    Cabin SystemWallboardEPS (epispastics polystyrene) colorful steel skin panel, EPS foam Density is 18kg/m³,75mm thick,steel 0.5mm thick, compound construction, anti-flame and heat-insulation, galvanized steel roof panel.
    Basement350mm depth ,Galvanized steel sheet and square steel pipe assembling,2 rows of grid plates made by flat bar and round steel,3 rows of diamond plates, galvanized. 2 ramps, external setting, 750 x 2000 mm ( W * L )/pc
    Air Circulation SystemIntake FanBlower Capacity: 25000m³/hExhaust FanBlower Capacity: 20000m³/h
    Power: 4kw/pcPower: 7.5kw/pc
    Quantity: 2 pcsQuantity: 1 pcs
    Model: Double-intake centrifugal fanModel: Double-intake centrifugal fan
    Air Volume: 25000m³/h , Air flow speed in the cabin:0.25m/s
    Heating systemBurnerItaly Riello G20 Diesel Burner, 200000Kcal/h. SUS304 Stainless steel heat exchanger ,argon arc welding.
    Heat energyMax Temp:80.C, Heating Time: 4-5min(20-60°C), Fuel Consumption: 4-5kg/vehicle
    Filter systemDual-filtering structurePrimary filter : Can Capture Granules Larger than 10μm
    Ceiling filter :600g high efficiency filter, can Capture Granules Bigger than 4μm
    Floor filter: fiberglass filter,exhaust activated carbon filter, Filtering rate>95%
    Lighting systemCeiling lights8Units×4Pcs=32Pcs×36W 900LUX ,with anti-explosion design .
    Side lights6Units×4Pcs=24Pcs×30W 900LUX ,with anti-explosion design .
    Control systemSpraying, heat spraying, time setting, lighting switch, failure indicator, thermostat, power supply switch, emergency stop. All motors are full voltage start.
    Environmental SystemMulti-Layer Fiberglasses Filter, active-carbon, and ensure a qualified exhaust according to the relevant state standards
