| Brand Name : | TARGET |
| Model Number : | TG-80A |
| Certification : | CE,ISO |
| Price : | $6000---10000 |
| Payment Terms : | T/T, L/C |
| Supply Ability : | 1000 setS/month |
| Delivery Time : | 5--7 days |
| Spray Booth Electric infrared lamp heating TG-80A | |||||||
| Inside dimension | 6900*4000*2800 (LxWxH) | Front door(mm) | 3000*2700 mm(W×H) | ||||
| Outside dimension | 7050*5560*3650 (LxWxH) | Total Power(Kw) | 44 Kw | ||||
| Cabin System | Wallboard | Rock wool colorful steel skin board ,75mm thick,steel 0.5mm thick, compound construction, anti-flame and heat-insulation, galvanized steel roof panel. | |||||
| Basement | 350mm depth ,Galvanized steel sheet and square steel pipe assembling,2 rows of grid plates made by flat bar and round steel,3 rows of diamond plates, galvanized. 2 ramps, external setting, 750 x 2000 mm ( W * L )/pc | ||||||
| Air Circulation System | Intake Fan | Blower Capacity: 25000m³/h | Exhaust Fan | Blower Capacity: 20000m³/h | |||
| Power: 7.5kw/pc , 970 rpm | Power: 5.5kw/pc , 970 rpm | ||||||
| Quantity: 1 pc | Quantity: 1 pc | ||||||
| Model: turbo fan | Model: turbo fan | ||||||
| Air Volume: 25000m³/h , Air flow speed in the cabin:0.25m/s | |||||||
| Heating system | 10 units infrared curing lamps for heating, 3pcs of each unit,1KW／pc.Total power:30KW. | ||||||
| Filter system | Dual-filtering structure | Primary filter : Can Capture Granules Larger than 10μm | |||||
| Ceiling filter :600g high efficiency filter, can Capture Granules Bigger than 4μm | |||||||
| Floor filter: fiberglass filter,exhaust activated carbon filter, Filtering rate>95% ,TSP≤1.4mg/m3 | |||||||
| Lighting system | Ceiling lights | 8Units×4Pcs=32Pcs×36W >900Lux ,with anti-explosion design . | |||||
| Side lights | no | ||||||
| Control system | Spraying, heat spraying, time setting, lighting switch, failure indicator, thermostat, power supply switch, emergency stop. All motors are full voltage start. | ||||||
| Environmental System | Multi-Layer Fiberglasses Filter, active-carbon, and ensure a qualified exhaust according to the relevant state standards | ||||||
|
|
